How To See the Architecture of A Loaded Model
如何查看已加载模型的结构
I spend several days to build up the online update weights feature in SGLang for RLHF workflow. Till now, I still couldn't figure out how to load the [name, weights] pairs into SGLang Engine. This is quite annoying, so I decide to dig into the code to figure out how it works.
我花了几天时间为 SGLang 的 RLHF 工作流程实现在线更新权重功能。直到现在，我仍然无法弄清楚如何将 [name, weights] 权重对加载到 SGLang 引擎中。这相当令人沮丧，因此我决定深入研究代码，弄清楚其工作原理。
Thus, this note is written to record my findings on how to investigate the structure of a model after it's loaded by Hugging Face or SGLang. We will first start with Hugging Face, and then move on to SGLang. All the codes are based on the meta-llama/Llama-3.2-1B-Instruct model.
因此，本文记录了我关于如何调查 Hugging Face 或 SGLang 加载后模型结构的发现。我们将首先从 Hugging Face 开始，然后转向 SGLang。所有代码均基于 meta-llama/Llama-3.2-1B-Instruct 模型。
Hugging Face
Loading a model from Hugging Face is quite simple with its direct API.
通过其直接 API 从 Hugging Face 加载模型非常简单。
from transformers import AutoModelForCausalLM, AutoTokenizer
model = AutoModelForCausalLM.from_pretrained("meta-llama/Llama-3.2-1B-Instruct", torch_dtype="bfloat16").to("cuda")
tokenizer = AutoTokenizer.from_pretrained("meta-llama/Llama-3.2-1B-Instruct")
print(model)Try to print the model, we get the following output:
尝试打印模型，我们得到以下输出：
LlamaForCausalLM(
(model): LlamaModel(
(embed_tokens): Embedding(128256, 2048)
(layers): ModuleList(
(0-15): 16 x LlamaDecoderLayer(
(self_attn): LlamaSdpaAttention(
(q_proj): Linear(in_features=2048, out_features=2048, bias=False)
(k_proj): Linear(in_features=2048, out_features=512, bias=False)
(v_proj): Linear(in_features=2048, out_features=512, bias=False)
(o_proj): Linear(in_features=2048, out_features=2048, bias=False)
(rotary_emb): LlamaRotaryEmbedding()
)
(mlp): LlamaMLP(
(gate_proj): Linear(in_features=2048, out_features=8192, bias=False)
(up_proj): Linear(in_features=2048, out_features=8192, bias=False)
(down_proj): Linear(in_features=8192, out_features=2048, bias=False)
(act_fn): SiLU()
)
(input_layernorm): LlamaRMSNorm((2048,), eps=1e-05)
(post_attention_layernorm): LlamaRMSNorm((2048,), eps=1e-05)
)
)
(norm): LlamaRMSNorm((2048,), eps=1e-05)
(rotary_emb): LlamaRotaryEmbedding()
)
(lm_head): Linear(in_features=2048, out_features=128256, bias=False)
)Let's go into the detailed component of the model, i.e., model.model, model.lm_head.
让我们深入了解模型的详细组成部分，即 model.model, model.lm_head 。
model.model
The whole class LlamaModel implements the Transformer decoder architecture.
整个类 LlamaModel 实现了 Transformer 解码器架构。
- Embedding Layer 嵌入层
embed_tokens: Embedding(128256, 2048)
128256: Vocabulary size.128256: 词汇表大小。2048: Dimensionality of each embedding vector.
2048: 每个嵌入向量的维度。- Maps discrete vocabulary indices to continuous embedding vectors.
将离散词汇索引映射为连续的嵌入向量。
- Decoder Layers 解码器层
layers: ModuleList (16 x LlamaDecoderLayer)
- A stack of 16 decoder layers. Each
LlamaDecoderLayercontains oneself_attn, mlp, input_layernorm, post_attention_layernorm.
由 16 个解码器层组成的堆栈。每个LlamaDecoderLayer包含一个self_attn, mlp, input_layernorm, post_attention_layernorm。
self_attn: LlamaSdpaAttention: Computes self-attention scores and aggregates contextual information.
self_attn: LlamaSdpaAttention：计算自注意力分数并聚合上下文信息。
q_proj: Projects input features into the query space. Input:2048, Output:2048.
q_proj: 将输入特征投影到查询空间。输入：2048，输出：2048。k_proj: Projects input features into the key space. Input:2048, Output:512(dimensionality reduction for efficiency).
k_proj: 将输入特征投影到键空间。输入：2048，输出：512（降维以提高效率）。v_proj: Projects input features into the value space. Input:2048, Output:512.
v_proj: 将输入特征投影到值空间。输入：2048，输出：512。o_proj: Projects attention outputs back to the input feature dimensionality. Input:2048, Output:2048.
o_proj: 将注意力输出投影回输入特征维度。输入：2048，输出：2048。rotary_emb: Rotary positional embeddings to encode sequence position.
rotary_emb: 使用旋转位置编码来表示序列位置。
mlp: LlamaMLP: Applies non-linear transformations through a multi-layer perceptron.
mlp: LlamaMLP: 通过多层感知机应用非线性变换。
gate_proj: Linear layer, Input:2048, Output:8192.
gate_proj: 线性层，输入：2048，输出：8192。up_proj: Linear layer, Input:2048, Output:8192.
up_proj: 线性层，输入：2048，输出：8192。down_proj: Linear layer, Input:8192, Output:2048.
down_proj: 线性层，输入维度：8192，输出维度：2048。act_fn: Activation functionSiLU(Swish) introduces non-linearity.
act_fn: 激活函数SiLU(Swish) 引入非线性变换。
input_layernorm: Applies RMSNorm to the layer input with dimensionality2048.
input_layernorm: 对维度为2048的层输入应用 RMSNorm 归一化。
post_attention_layernorm: Applies RMSNorm after the attention mechanism.
post_attention_layernorm: 在注意力机制后应用 RMSNorm 归一化。
- Global Normalization 全局归一化
norm: LlamaRMSNorm((2048,), eps=1e-05)
- Applies RMSNorm to the final decoder output for stable feature scaling.
对最终解码器输出应用 RMSNorm，实现稳定的特征缩放。
- Rotary Positional Embedding
旋转位置编码
rotary_emb: LlamaRotaryEmbedding()
- Encodes positional information using rotary embeddings to enhance sequence modeling.
采用旋转嵌入技术编码位置信息，以增强序列建模能力。
model.lm_head
lm_head: Linear(in_features=2048, out_features=128256, bias=False)- A linear layer that maps the decoder's output features (dim:
2048) to the vocabulary size (128256).
一个将解码器输出特征（维度：2048）映射到词汇表大小（128256）的线性层。 - No bias term: Reduces the number of trainable parameters and computation complexity.
无偏置项：减少可训练参数数量和计算复杂度。
Model State Dict 模型状态字典
In Pytorch, state_dict is a core mechanism for saving and loading the parameters and optimizer states of a model. Here is its function and principle:
在 PyTorch 中， state_dict 是保存和加载模型参数及优化器状态的核心机制。以下是其功能与原理：
state_dict: A Python dictionary object that maps each layer to its parameter tensor.
state_dict：一个 Python 字典对象，将每个层映射到其参数张量。model.state_dict(): Returns the state dictionary of the model, containing all the weights and biases.
model.state_dict()：返回模型的状态字典，包含所有权重和偏置参数。torch.save(model.state_dict(), PATH): Saves the state dictionary to a file.
torch.save(model.state_dict(), PATH): 将状态字典保存到文件中。model.load_state_dict(torch.load(PATH)): Loads the state dictionary from a file.
model.load_state_dict(torch.load(PATH)): 从文件加载状态字典。
As you see, state dict is a dictionary, and contains the name and weights of each layer.
如你所见，状态字典是一个字典，包含每一层的名称和权重。
We first get the state dict of the model, and then get its VRAM usage.
我们首先获取模型的状态字典，然后计算其显存占用情况。
state_dict = model.state_dict()
total_memory = 0
for name, param in state_dict.items():
param_memory = param.numel() * param.element_size() # numel() gives the number of elements, element_size() gives the size in bytes
total_memory += param_memory
total_memory_mb = total_memory / (1024 * 1024)
print(f"Total memory usage of the state_dict: {total_memory_mb:.2f} MB")
# Total memory usage of the state_dict: 2858.13 MBA 1B model in bfloat16 precision takes about 2.8GB VRAM, that's reasonable.
一个采用 bfloat16 精度的 10 亿参数模型大约占用 2.8GB 显存，这个数值是合理的。
print(state_dict.keys())
# odict_keys(['model.embed_tokens.weight', 'model.layers.0.self_attn.q_proj.weight', 'model.layers.0.self_attn.k_proj.weight', 'model.layers.0.self_attn.v_proj.weight', 'model.layers.0.self_attn.o_proj.weight', 'model.layers.0.mlp.gate_proj.weight', 'model.layers.0.mlp.up_proj.weight', 'model.layers.0.mlp.down_proj.weight', 'model.layers.0.input_layernorm.weight', 'model.layers.0.post_attention_layernorm.weight', 'model.layers.1.self_attn.q_proj.weight', 'model.layers.1.self_attn.k_proj.weight', 'model.layers.1.self_attn.v_proj.weight', 'model.layers.1.self_attn.o_proj.weight', 'model.layers.1.mlp.gate_proj.weight', 'model.layers.1.mlp.up_proj.weight', 'model.layers.1.mlp.down_proj.weight', 'model.layers.1.input_layernorm.weight', 'model.layers.1.post_attention_layernorm.weight', 'model.layers.2.self_attn.q_proj.weight', 'model.layers.2.self_attn.k_proj.weight', 'model.layers.2.self_attn.v_proj.weight', 'model.layers.2.self_attn.o_proj.weight', 'model.layers.2.mlp.gate_proj.weight', 'model.layers.2.mlp.up_proj.weight', 'model.layers.2.mlp.down_proj.weight', 'model.layers.2.input_layernorm.weight', 'model.layers.2.post_attention_layernorm.weight', 'model.layers.3.self_attn.q_proj.weight', 'model.layers.3.self_attn.k_proj.weight', 'model.layers.3.self_attn.v_proj.weight', 'model.layers.3.self_attn.o_proj.weight', 'model.layers.3.mlp.gate_proj.weight', 'model.layers.3.mlp.up_proj.weight', 'model.layers.3.mlp.down_proj.weight', 'model.layers.3.input_layernorm.weight', 'model.layers.3.post_attention_layernorm.weight', 'model.layers.4.self_attn.q_proj.weight', 'model.layers.4.self_attn.k_proj.weight', 'model.layers.4.self_attn.v_proj.weight', 'model.layers.4.self_attn.o_proj.weight', 'model.layers.4.mlp.gate_proj.weight', 'model.layers.4.mlp.up_proj.weight', 'model.layers.4.mlp.down_proj.weight', 'model.layers.4.input_layernorm.weight', 'model.layers.4.post_attention_layernorm.weight', 'model.layers.5.self_attn.q_proj.weight', 'model.layers.5.self_attn.k_proj.weight', 'model.layers.5.self_attn.v_proj.weight', 'model.layers.5.self_attn.o_proj.weight', 'model.layers.5.mlp.gate_proj.weight', 'model.layers.5.mlp.up_proj.weight', 'model.layers.5.mlp.down_proj.weight', 'model.layers.5.input_layernorm.weight', 'model.layers.5.post_attention_layernorm.weight', 'model.layers.6.self_attn.q_proj.weight', 'model.layers.6.self_attn.k_proj.weight', 'model.layers.6.self_attn.v_proj.weight', 'model.layers.6.self_attn.o_proj.weight', 'model.layers.6.mlp.gate_proj.weight', 'model.layers.6.mlp.up_proj.weight', 'model.layers.6.mlp.down_proj.weight', 'model.layers.6.input_layernorm.weight', 'model.layers.6.post_attention_layernorm.weight', 'model.layers.7.self_attn.q_proj.weight', 'model.layers.7.self_attn.k_proj.weight', 'model.layers.7.self_attn.v_proj.weight', 'model.layers.7.self_attn.o_proj.weight', 'model.layers.7.mlp.gate_proj.weight', 'model.layers.7.mlp.up_proj.weight', 'model.layers.7.mlp.down_proj.weight', 'model.layers.7.input_layernorm.weight', 'model.layers.7.post_attention_layernorm.weight', 'model.layers.8.self_attn.q_proj.weight', 'model.layers.8.self_attn.k_proj.weight', 'model.layers.8.self_attn.v_proj.weight', 'model.layers.8.self_attn.o_proj.weight', 'model.layers.8.mlp.gate_proj.weight', 'model.layers.8.mlp.up_proj.weight', 'model.layers.8.mlp.down_proj.weight', 'model.layers.8.input_layernorm.weight', 'model.layers.8.post_attention_layernorm.weight', 'model.layers.9.self_attn.q_proj.weight', 'model.layers.9.self_attn.k_proj.weight', 'model.layers.9.self_attn.v_proj.weight', 'model.layers.9.self_attn.o_proj.weight', 'model.layers.9.mlp.gate_proj.weight', 'model.layers.9.mlp.up_proj.weight', 'model.layers.9.mlp.down_proj.weight', 'model.layers.9.input_layernorm.weight', 'model.layers.9.post_attention_layernorm.weight', 'model.layers.10.self_attn.q_proj.weight', 'model.layers.10.self_attn.k_proj.weight', 'model.layers.10.self_attn.v_proj.weight', 'model.layers.10.self_attn.o_proj.weight', 'model.layers.10.mlp.gate_proj.weight', 'model.layers.10.mlp.up_proj.weight', 'model.layers.10.mlp.down_proj.weight', 'model.layers.10.input_layernorm.weight', 'model.layers.10.post_attention_layernorm.weight', 'model.layers.11.self_attn.q_proj.weight', 'model.layers.11.self_attn.k_proj.weight', 'model.layers.11.self_attn.v_proj.weight', 'model.layers.11.self_attn.o_proj.weight', 'model.layers.11.mlp.gate_proj.weight', 'model.layers.11.mlp.up_proj.weight', 'model.layers.11.mlp.down_proj.weight', 'model.layers.11.input_layernorm.weight', 'model.layers.11.post_attention_layernorm.weight', 'model.layers.12.self_attn.q_proj.weight', 'model.layers.12.self_attn.k_proj.weight', 'model.layers.12.self_attn.v_proj.weight', 'model.layers.12.self_attn.o_proj.weight', 'model.layers.12.mlp.gate_proj.weight', 'model.layers.12.mlp.up_proj.weight', 'model.layers.12.mlp.down_proj.weight', 'model.layers.12.input_layernorm.weight', 'model.layers.12.post_attention_layernorm.weight', 'model.layers.13.self_attn.q_proj.weight', 'model.layers.13.self_attn.k_proj.weight', 'model.layers.13.self_attn.v_proj.weight', 'model.layers.13.self_attn.o_proj.weight', 'model.layers.13.mlp.gate_proj.weight', 'model.layers.13.mlp.up_proj.weight', 'model.layers.13.mlp.down_proj.weight', 'model.layers.13.input_layernorm.weight', 'model.layers.13.post_attention_layernorm.weight', 'model.layers.14.self_attn.q_proj.weight', 'model.layers.14.self_attn.k_proj.weight', 'model.layers.14.self_attn.v_proj.weight', 'model.layers.14.self_attn.o_proj.weight', 'model.layers.14.mlp.gate_proj.weight', 'model.layers.14.mlp.up_proj.weight', 'model.layers.14.mlp.down_proj.weight', 'model.layers.14.input_layernorm.weight', 'model.layers.14.post_attention_layernorm.weight', 'model.layers.15.self_attn.q_proj.weight', 'model.layers.15.self_attn.k_proj.weight', 'model.layers.15.self_attn.v_proj.weight', 'model.layers.15.self_attn.o_proj.weight', 'model.layers.15.mlp.gate_proj.weight', 'model.layers.15.mlp.up_proj.weight', 'model.layers.15.mlp.down_proj.weight', 'model.layers.15.input_layernorm.weight', 'model.layers.15.post_attention_layernorm.weight', 'model.norm.weight', 'lm_head.weight'])Different from the model architecture, the state dict unsqueezes the name and weights of all the components.
与模型架构不同，状态字典会展开所有组件的名称和权重。
Also, dict(model.named_parameters()).keys() gives the same result.
此外， dict(model.named_parameters()).keys() 也给出了相同的结果。
SGLang
After seeing the architecture of a loaded model by Hugging Face, it's much clear for SGLang. Still take the example of Llama-3.2-1B-Instruct model, here is the llama file how it's loaded.
通过查看 Hugging Face 加载的模型架构后，SGLang 的情况就清晰多了。仍以 Llama-3.2-1B-Instruct 模型为例，以下是加载该模型的 llama 文件内容。
Take a step in: 进一步深入：
def load_weights(self, weights: Iterable[Tuple[str, torch.Tensor]]):
embed_tokens_weight = None
stacked_params_mapping = [
# (param_name, shard_name, shard_id)
(".qkv_proj", ".q_proj", "q"),
(".qkv_proj", ".k_proj", "k"),
(".qkv_proj", ".v_proj", "v"),
(".gate_up_proj", ".gate_proj", 0),
(".gate_up_proj", ".up_proj", 1),
]
params_dict = dict(self.named_parameters())
load_tie_word_embeddings = (
hasattr(self.config, "tie_word_embeddings")
and self.config.tie_word_embeddings
and "lm_head.weight" in params_dict
)
for name, loaded_weight in weights:
if "rotary_emb.inv_freq" in name or "projector" in name:
continue
if "rotary_emb.cos_cached" in name or "rotary_emb.sin_cached" in name:
# Models trained using ColossalAI may include these tensors in
# the checkpoint. Skip them.
continue
if name.startswith("model.vision_tower") and name not in params_dict:
continue
for param_name, weight_name, shard_id in stacked_params_mapping:
if weight_name not in name:
continue
name = name.replace(weight_name, param_name)
# Skip loading extra bias for GPTQ models.
if name.endswith(".bias") and name not in params_dict:
continue
param = params_dict[name]
weight_loader = param.weight_loader
weight_loader(param, loaded_weight, shard_id)
break
else:
# Skip loading extra bias for GPTQ models.
if name.endswith(".bias") and name not in params_dict:
continue
# Skip loading kv_scale from ckpts towards new design.
if name.endswith(".kv_scale") and name not in params_dict:
continue
param = params_dict[name]
weight_loader = getattr(param, "weight_loader", default_weight_loader)
weight_loader(param, loaded_weight)
if load_tie_word_embeddings and name == "model.embed_tokens.weight":
embed_tokens_weight = loaded_weight
if load_tie_word_embeddings:
# Tie output embedding layer to input embedding layer, to solve issues where lm_head.weight is missing
param = self.lm_head.weight
weight_loader = getattr(param, "weight_loader", default_weight_loader)
if embed_tokens_weight is not None:
weight_loader(param, embed_tokens_weight)
apply_torchao_config_(self, params_dict, set(["proj.weight"]))This function defined how a model's weights are loaded after parameter name mapping.
该函数定义了在参数名称映射后如何加载模型的权重。
stacked_params_mapping = [
# (param_name, shard_name, shard_id)
(".qkv_proj", ".q_proj", "q"),
(".qkv_proj", ".k_proj", "k"),
(".qkv_proj", ".v_proj", "v"),
(".gate_up_proj", ".gate_proj", 0),
(".gate_up_proj", ".up_proj", 1),
]Generally, each q_proj, k_proj, v_proj is mapped into a qkv_proj, and then named with q, k, v shard id. gate_proj and up_proj are mapped into gate_up_proj with shard id 0 and 1 respectively.
通常，每个 q_proj, k_proj, v_proj 会被映射到一个 qkv_proj ，然后以 q, k, v 分片 ID 命名。 gate_proj 和 up_proj 则分别映射到带有分片 ID 0 和 1 的 gate_up_proj 。
Then, how to see the state dict of a loaded model?
那么，如何查看已加载模型的状态字典呢？
def get_weights_by_name(
self, name: str, truncate_size: int = 100, tp_size: int = 1
) -> Optional[torch.Tensor]:
"""Get the weights of the parameter by its name. Similar to `get_parameter` in Hugging Face.
Only used for unit test with an unoptimized performance.
For optimized performance, please use torch.save and torch.load.
"""
try:
mapped_name = name
mapped_shard_id = None
for param_name, weight_name, shard_id in self.stacked_params_mapping:
if weight_name in name:
mapped_name = name.replace(weight_name, param_name)
mapped_shard_id = shard_id
break
params_dict = dict(self.named_parameters())
if mapped_name in params_dict:
param = params_dict[mapped_name]
if mapped_shard_id is not None:
if mapped_shard_id in ["q", "k", "v"]:
num_heads = self.config.num_attention_heads // tp_size
num_kv_heads = self.config.num_key_value_heads // tp_size
head_dim = (
self.config.hidden_size // self.config.num_attention_heads
)
if mapped_shard_id == "q":
offset = 0
size = num_heads * head_dim
elif mapped_shard_id == "k":
offset = num_heads * head_dim
size = num_kv_heads * head_dim
elif mapped_shard_id == "v":
offset = (num_heads + num_kv_heads) * head_dim
size = num_kv_heads * head_dim
weight = param.data.narrow(0, offset, size)
elif mapped_shard_id in [0, 1]:
intermediate_size = self.config.intermediate_size
hidden_size = self.config.hidden_size
slice_size = intermediate_size // tp_size
if mapped_shard_id == 0: # gate_proj
offset = 0
size = slice_size
elif mapped_shard_id == 1: # up_proj
offset = slice_size
size = slice_size
weight = param.data.narrow(0, offset, size)
else:
weight = param.data
else:
weight = param.data
if tp_size > 1 and ("o_proj" in name or "down_proj" in name):
gathered_weights = [
torch.zeros_like(weight) for _ in range(tp_size)
]
torch.distributed.all_gather(gathered_weights, weight)
weight = torch.cat(gathered_weights, dim=1)
return weight.cpu().to(torch.float32).numpy().tolist()[:truncate_size]
else:
return NoneThis function defined how to get the weights of a parameter by its name. Read and write are the two sides of the same coin. 【TODO: add tp illustration】
该函数定义了如何通过参数名称获取其权重。读取和写入是同一枚硬币的两面。【待办：添加类型说明图示】
Note that for o_proj and down_proj, the weights should be gathered by all the GPUs.
注意，对于 o_proj 和 down_proj ，权重应由所有 GPU 共同收集。
Read is much more difficult than write/load. You can load a new parameter by self.load_weights([(name, weights)]), but how to get the weights of a parameter? Refer to this docs decribing the update weights from distributed workers.
读取比写入/加载要困难得多。你可以通过 self.load_weights([(name, weights)]) 加载一个新参数，但如何获取某个参数的权重？请参阅这份描述从分布式工作节点更新权重的文档。
